Cover: 46% were sewers — what the evidence shows about sinkholes
|

Sinkholes: What the Evidence Shows

Key takeaways · 11 min read

  • Sinkholes in nature form in soluble rock such as limestone; most urban collapses start with leaking pipes.
  • Damaged sewers caused 46% of South Korea’s ground collapses in 2019–2023.
  • US sinkholes cluster in a small share of karst land, and the country has no national loss database.
  • Seoul’s road radar surveys now find fewer cavities, but the radar cannot see deep failures.

A road in Myeongil-dong, in eastern Seoul, gave way beneath traffic on the evening of 24 March 2025. The hole measured about 22 metres by 18 metres and 16 metres deep. One person was injured, and a motorcyclist fell in and died. Two months earlier, near Tokyo, a lorry had dropped into a sinkhole in Yashio, and its 74-year-old driver was not recovered for three months.

Some sinkholes are natural. In limestone regions such as Florida, rainwater slowly dissolves the rock until the ground above can no longer hold. In cities, though, most holes that open under roads have a more ordinary cause: water escaping from old sewer and water pipes and carrying soil away until a void forms just under the asphalt.

This article covers both kinds of sinkhole: how often they happen, what causes them, whether ground radar can find them in time, and why Florida’s sinkhole insurance claims ended up measuring something other than sinkholes.

A pointillist illustration: a city road at night with a large dark hole in the asphalt, broken slabs at its edge, traffic cones joined by yellow tape, and two amber streetlamps.
A road collapse at night. In cities, most sinkholes start with a leaking pipe.

Two different hazards with one name

Geologists separate natural sinkholes from human-induced ground collapse. Natural ones form in karst, terrain underlain by soluble rock such as limestone, dolomite or gypsum. The US Geological Survey puts about 18% of the United States over soluble rocks, and about 25% over karst features or the potential to develop them. Florida, Kentucky, Tennessee, Missouri, Pennsylvania and Texas are among the most affected states.

Urban collapses usually have nothing to do with the rock. A crack or joint failure in a buried pipe lets soil wash into it, especially when heavy rain or high groundwater pushes water through the ground. Over months or years a cavity grows upwards until the road surface is only a thin shell. The collapse itself can be sudden, but the process behind it is slow and, in principle, detectable.

Leaking pipes are the main urban cause

The clearest data come from East Asia, where governments count road collapses. A National Assembly Library compilation of South Korean Ministry of Land, Infrastructure and Transport data recorded 2,119 ground subsidence incidents between 2015 and 2024: about 200 a year, peaking at 338 in 2018 and falling to 102 in 2024. Of 957 incidents between 2019 and 2023, 46% were attributed to damaged sewer pipes and 18% to poor compaction of soil after earlier works, with smaller shares for excavation and other underground facilities.

In Seoul, a Korea Institute of Geoscience and Mineral Resources analysis, cited in later research, attributed about 85% of some 3,200 subsidence cases between 2010 and mid-2015 to sewer damage. A 2026 study of 303 incidents in Gyeonggi Province found sewer damage behind 39%, poor backfill behind 23% and excavation behind 14%; sewer-related collapses peaked in the summer monsoon.

What causes urban ground collapse in South Korea

Ground subsidence incidents by cause, 2019–2023 (957 incidents).

Damaged sewer pipes46%
Poor compaction or backfill18%
Faulty excavation9%
Other underground facilities7%

Ministry of Land, Infrastructure and Transport data as reported in 2025. Shares rounded; the remainder are other or unknown causes.

Japan records about 10,000 road sinkholes a year: 9,124 in 2020, 9,967 in 2021 and 10,548 in 2022, according to national figures cited in a 2024 engineering paper. Cracked or damaged buried pipes are the most common cause. At the end of fiscal 2019 the transport ministry attributed about 2,900 cave-ins a year to sewer and other pipeline facilities, and reported that cave-ins rise once sewers pass about 30 years in service.

Road sinkholes in Japan

Road cave-ins recorded nationally each year.

20209,124
20219,967
202210,548

National figures cited by Rodrigues Neto and colleagues, 2024. The most common cause was damage to buried pipes.

Europe shows the same mechanism. In 2016, Emilia Kuliczkowska of Kielce University of Technology analysed 100 road collapses caused by defective sewers: the average covered about 49 square metres and the smallest just 0.12. Her conclusion was that outside limestone karst, road collapses are caused mainly by leaking water mains, storm drains and sewers.

Karst sinkholes in Florida and the United States

Natural sinkholes cluster in a few places. In 2023, Nathan Wood and colleagues at the USGS mapped sinkhole susceptibility across the conterminous United States. About 68% of karst and pseudokarst land had no mapped closed depressions and was rated very low susceptibility, while the high and very high classes, 17% of that land, contained 94% to 99% of the known sinkholes in three state databases. Florida had the largest area of high or very high susceptibility, about 50,000 square kilometres.

A pointillist illustration: a manhole cover set in dark asphalt, a crack running from it to a shallow dip filled with water, lit by warm amber light.
A crack and a dip in the road. Voids usually form out of sight before the surface fails.

Building makes it worse. A preliminary study in Beacon Woods, Florida, found sinkholes about ten times more common in urban areas than in undeveloped land and pointed to leaking water, sewer and septic lines and to stormwater drainage. A projection by the same USGS team found that expected changes in climate and land use did not substantially shift the national hotspots.

Nobody counts sinkhole deaths nationally, in part because they are rare. The 2023 USGS paper noted that the United States has no national database of sinkhole occurrences or losses. The case most people remember is Seffner, Florida, where Jeff Bush was swallowed in his bedroom in February 2013; his body was never recovered, and the same site reopened in 2015 and 2023. The most quoted cost figure, at least $300 million a year in US damage, comes from a 2015 USGS conference paper by David Weary, who wrote that the true total was probably much higher and that no federal agency is required to collect it.

Where US sinkholes are

Sinkhole susceptibility across karst and pseudokarst land in the conterminous United States.

68%of karst and pseudokarst land rated very low susceptibility
94–99%of known sinkholes in three state databases fell in the high and very high classes

Wood, Doctor, Alder and Jones, Frontiers in Earth Science, 2023.

Can radar find the voids in time?

Because urban cavities grow slowly under the road surface, cities survey them with vehicle-mounted ground-penetrating radar. Over ten years Seoul has surveyed about 33,000 kilometres of road and found about 7,760 cavities. City figures reported in October 2025 show the rate found falling from 0.41 cavities per kilometre in 2015 to 0.08 in 2025, which the city attributes to repairs and pipe replacement. It plans to survey 18,000 kilometres a year from 2026.

Vehicle-mounted radar has limits. A study of 204 confirmed cavities in Seoul found it could see to about 1.5 to 2 metres, and most of the cavities it found sat within 0.4 metres of the surface. The Myeongil-dong collapse began about 16 metres down. In Japan, national-road surveys from 2020 to 2022 found about 0.5 possible cavities per kilometre, and municipal roads in the city of Matsuyama, with denser pipe networks, about 4.8. These are possible cavities that need confirmation, and the figures come from a paper by the system’s developers.

A 2018 study in Natural Hazards modelled sinkhole susceptibility for Seoul’s sewers from pipe length, age, depth, size, slope and material. Its accuracy, measured by the area under the curve, was 0.75: useful for ranking pipes, far from reliable for any one street.

Cavities found by road radar in Seoul

Cavities found per kilometre of road surveyed.

20150.41
2025 (to September)0.08

Seoul Metropolitan Government figures reported in October 2025. The survey reaches about 1.5–2 m below the surface.

What the investigations found

In December 2025 the Korean government’s investigation committee reported that the Myeongil-dong collapse began when a wedge-shaped block of weathered rock failed where three fractures met. It listed as contributing factors a fall in groundwater linked to tunnel works for the Sejong–Pocheon Expressway below the road, an old sewer that had been flagged for cracks in a 2022 inspection but not repaired, and gaps in construction management.

The Yashio collapse in Japan, on 28 January 2025, grew to at least 40 metres across and about 16 metres deep. While the damaged sewer was bypassed, about 1.2 million residents were asked to cut their water use. In February 2026 an expert committee’s final report blamed corrosion of the sewer pipe; an earlier survey had failed to capture images of it, so the risk was underestimated.

A five-lane road in Hakata, Fukuoka, collapsed on 8 November 2016 during work on a subway extension, and reopened a week later. In Bangkok, on 24 September 2025, a hole about 30 metres across opened outside Vajira Hospital when soil flowed into a subway tunnel through a cracked joint, worsened by a broken water main. Nobody was hurt. Geologists say the Guatemala City collapse of 2010, often called a sinkhole, was a piping failure in volcanic fill caused by a burst drain rather than dissolving rock.

A pointillist illustration: a Florida house with a white fence and a palm tree, and a small dark depression opening in the front lawn, with an amber porch light.
A dip in a lawn. Most sinkhole insurance claims in Florida were not collapses at all.

What Florida’s insurance claims measured

In Florida, sinkholes became an insurance crisis. A 2010 review by the state’s Office of Insurance Regulation counted 24,671 sinkhole claims between 2006 and 2010, costing about $1.4 billion at an average of $70,412 a claim. Claims climbed from 2,360 in 2006 to 7,244 in 2009. Hernando, Pasco and Hillsborough counties produced two-thirds of them, but claims also rose in Miami-Dade and Broward, which the regulator said were generally not subject to sinkhole activity.

Only 1.1% of closed claims involved a catastrophic ground cover collapse, the kind of sudden hole people picture, while more than half were classed as subsidence, slow settling that caused cracks. In a sample of 110 paid claims, 56% of the homes had not been repaired. The regulator referred fewer than 1% of claims to its fraud division, so the report does not show how many were fraudulent, only that the payments often did not go into repairs.

The legislature tightened the law in 2011, defining structural damage, setting a two-year limit for claims and giving weight to the insurer’s engineering report. At the state-backed insurer Citizens, claims fell to 2,386 in 2012 and were projected at about 900 in 2013, an estimated 80% drop from 2011. Basic Florida policies now need only cover catastrophic ground cover collapse; wider sinkhole cover is optional. We looked at a similar gap between what people think they are covered for and what policies pay in our article on flood insurance.

Florida sinkhole claims, 2006–2010

Claims reported to the Office of Insurance Regulation data call.

MeasureFigure
Claims, 20062,360
Claims, 20097,244
Total cost, 2006–2010About $1.4 billion
Closed claims that were catastrophic collapses1.1%
Sampled paid claims where the home was not repaired56%

Florida Office of Insurance Regulation, 2010 Sinkhole Data Call report. 2010 is a partial year.

How big is the risk for one household?

For most people, it is small, and so are most urban collapses: Kuliczkowska’s average was 49 square metres, and large holes like Yashio make up only about 2% of sewer-related incidents in Japan. In the Gyeonggi study, the cause of a collapse was significantly associated with vehicle damage and season, but not with injuries. The cases that reach the news are the rare ones.

Risk is concentrated in particular places. In karst areas it depends on the rock under a particular neighbourhood, and on local maps that show known sinkholes. In cities it depends on the age and condition of the pipes under the road, which is why the same aging water and sewer networks behind water main breaks also sit behind most road collapses. South Korea’s Special Act on Underground Safety Management, passed in 2016 and in force since 2018, requires underground safety assessments before large excavations and regular inspections of underground facilities, because most collapses are man-made and therefore preventable.

If you think you have a sinkhole: what the USGS suggests, in order

The USGS says it does not investigate individual sinkholes on private property, but it does publish a short sequence for owners. It is summarised here with its limits.

The warning signs it lists are tilted floors, misaligned door frames, and cracks or small holes in and around foundations. It also lists surface water draining into a depression or hole, and streams that vanish.

The USGS sequence for a suspected sinkhole
StepWhat to do
1Rule out human causes first: leaking underground pipes, poor drainage, or old construction pits and buried material that has settled.
2If you are confident it is natural, check your homeowner’s insurance. Most policies in most states do not cover natural sinkhole damage, but this varies by state.
3Contact the utility company if gas, electric, water or sewer lines could be affected.
4Contact your State Geological Survey.
5Hire a professional geologist or geotechnical engineer.

The ordering has a practical point, which the USGS pages imply: many holes in built-up areas turn out to be pipe leaks or drainage failures that a plumber or utility can fix, while true natural collapse in soluble rock is a geotechnical question.

We could not confirm some things. The pages we read do not say to keep away from the edge or to call emergency services; that is our note, not the USGS’s: if the ground is actively opening, or you smell gas, leave the area and call your local emergency number or the utility’s emergency line. We also found no dated national annual damage figure on the pages we could open; one 2020 USGS page says “several hundred million dollars” with no year and adds that the true cost is likely higher.

Questions people ask

What causes sinkholes in cities?

Mostly leaking sewer and water pipes that wash soil away, with poorly compacted backfill and excavation also contributing. In Korea, damaged sewers caused 46% of incidents in 2019–2023.

How common are sinkholes?

South Korea recorded about 200 ground subsidence incidents a year from 2015 to 2024, and Japan about 10,000 road sinkholes a year, most of them small.

Can sinkholes be detected before they collapse?

Road radar finds many shallow cavities, and the rate Seoul finds has fallen sharply. It reaches only about 1.5 to 2 metres deep, though, so deeper failures can be missed.

Does home insurance cover sinkholes?

It depends on the policy and country. In Florida, basic policies must cover only catastrophic ground cover collapse; wider sinkhole cover is optional.

What are the warning signs of a sinkhole?

Local authorities list signs such as new cracks in roads or walls, sagging pavement, doors that stop closing, and puddles or depressions that were not there before. Report them rather than investigating the hole yourself.

The short version

  • Sinkholes in nature form in soluble rock such as limestone; most urban collapses start with leaking pipes.
  • Damaged sewers caused 46% of South Korea’s ground collapses in 2019–2023.
  • US sinkholes cluster in a small share of karst land, and the country has no national loss database.
  • Seoul’s road radar surveys now find fewer cavities, but the radar cannot see deep failures.
  • Only 1.1% of closed Florida sinkhole claims in the 2010 review were catastrophic collapses.

This article summarises published research, government data and news reports on sinkholes and ground collapse. It is not engineering, legal or insurance advice and cannot tell you whether a particular property is at risk. If you see a new hole, depression or crack in a road or near a building, keep away from it and report it to the local authority or emergency services.

Further reading. Wood, Doctor, Alder and Jones, ‘Current and future sinkhole susceptibility in karst and pseudokarst areas of the conterminous United States’, Frontiers in Earth Science, 2023, is the best overview of natural sinkholes. Kuliczkowska, 2016, explains how leaking sewers cause road collapses.

Sources

  1. Weary DJ, Doctor DH. Karst in the United States: A Digital Map Compilation and Database. US Geological Survey Open-File Report 2014-1156, 2014.
  2. Weary DJ. The cost of karst subsidence and sinkhole collapse in the United States compared with other natural hazards. Proceedings of the 14th Multidisciplinary Conference on Sinkholes, 2015:433–446. doi:10.5038/9780991000951.1062.
  3. Wood N, Doctor DH, Alder JR, Jones JM. Current and future sinkhole susceptibility in karst and pseudokarst areas of the conterminous United States. Frontiers in Earth Science, 2023;11:1207689. doi:10.3389/feart.2023.1207689.
  4. Veni G, Brashear S, Glasbrenner J. Building codes to minimize cover collapses in sinkhole-prone areas. Proceedings of the 14th Multidisciplinary Conference on Sinkholes, 2015:471–476. doi:10.5038/9780991000951.1063.
  5. Kuliczkowska E. An analysis of road pavement collapses and traffic safety hazards resulting from leaky sewers. Baltic Journal of Road and Bridge Engineering, 2016;11(4):251–258. doi:10.3846/bjrbe.2016.29.
  6. Rodrigues Neto J, Shinohara J, Kato Y, and colleagues. Advancements and applications of GMS3: a surface and subsurface unified database system. Journal of Physics: Conference Series, 2024;2887:012022. doi:10.1088/1742-6596/2887/1/012022.
  7. Park J, Chung Y, Hong G. Reinforcement effect of a concrete mat to prevent ground collapses due to buried pipe damage. Applied Sciences, 2020;10(16):5439.
  8. Kim K, Kim J, Kwak TY, Chung CK. Logistic regression model for sinkhole susceptibility due to damaged sewer pipes. Natural Hazards, 2018;93(2):765–785. doi:10.1007/s11069-018-3323-y.
  9. Kim J, Song K, Koo DD, Han S. Seasonal and regional patterns of ground subsidence associated with urban water and sewer infrastructure failures. Water, 2026;18(4):448.
  10. Yoon JS, Youm M, Park S, Kim J. Technique for detecting subsurface cavities of urban road using multichannel GPR equipment. 2020.
  11. National Assembly Library of Korea. Ground subsidence (sinkholes) in data. Data & Law, No. 29, May 2025.
  12. Florida Office of Insurance Regulation. Report on Review of the 2010 Sinkhole Data Call. November 2010.
  13. Florida Senate. Bill analysis, SB 408 (2011) and SB 416 (2014).
  14. Ministry of Land, Infrastructure and Transport, Central Underground Accident Investigation Committee. Findings on the Myeongil-dong ground collapse, as reported December 2025.
  15. USGS. I have, or think I have, a sinkhole on my property. What should I do? usgs.gov.
  16. USGS. National Preparedness Month 2020: Landslides and Sinkholes, Sept. 29, 2020. usgs.gov.
  17. USGS Water Science School. Sinkholes. usgs.gov.
